SPECIFICATIONS

Application: Desktop

Back I/O Ports: 1x RJ45

Battery Included: no

Brand Name: MACHINIST

Chipset: Intel B85

Chipset Manufacturer: Intel

Form Factor: Micro-ATX

High-concerned chemical: None

Max LAN Speed: 1000Mbps

Maximum Ram Capacity: 128 GB

Memory channel: Double

Number Of Memory Slots: 4

Number of M.2: 1

Number of PCI: 0

Number of PCIe x 1: 1

Number of PCIe x 16: 1

Number of PCIe x 4: 0

Onboard Connectors & Header: 24-pin Main Power Connector,CPU Fan Connector(s),AAFP Connector

Onboard LAN: 1x RJ45

Origin: Mainland China

PCI - E standards: PCI-E 3.0

Package: Yes

Ports: USB 3.0

Processor compatibility: Intel Xeon

RAID Supported: no

Socket Type: LGA 2011-3

Special Features: NONE

Storage Interface Type: SATA

Support Memory Type: DDR4

Support USB Type: USB 2.0,USB 3.0

Supports M.2 SSD: 2280

Usage Scenario: Gaming,Audio & Video,Office

With CPU: No

> > (Included accessories: 1 I/O shield, 1 SATA cable, 1 IGA 2011 heat sink. If any of the gifts are lost, it cannot be used as a reason for a refund. Please understand!)

> > When installing the memory modules, please pay attention to the sequence of the memory slot positions, as shown in the figure.

> > Motherboard Information:

Brand: MACHINIST.

Motherboard Model: X99 PR9.

Processor: Supports LGA 2011-3 series.

Chipset: B85/Q87/C226 Chipset.

> > Memory:

Technology: Dual-channel DDR4. Supports 2133/2400/2666/3000/3200 MHz.

Maximum capacity: 128GB (32G × 4).

Memory slots: 4 * 288 PIN DDR4.

Note #1: Please use international brands such as Samsung, Kingston, SanDisk, Micron, etc. Other brands may be incompatible.

>> Post I/O:

PS/2: 1 KB interface + 1 MS interface.

USB interfaces: 6 USB 2.0; 2 USB 3.0.

Ethernet: 1 Gigabit network card.

Audio: 1 (Mic-in, Line-out, Line-in).

> > Other:

TPM interface: For ASUS LPC-14Pin-2.0

SATA interface: 2 (SATA 2.0), 1 (SATA 3.0).

M.2: 1 (NVMe/SATA).

PCIe: 1 (PCIe 16x), 1 (PCIe 1x).

Overall dimensions: 215mm * 185mm. > > Attention:

(1) The color of the bottom plate may vary by batch, but it will not affect the use of the product. The product is constantly being optimized and upgraded.

(2) Due to manual measurement, please allow for an error of 1-3mm.

(3) Due to different displays and different light conditions, the pictures may not accurately represent the actual color of the item. Thank you for your understanding.

(4) This platform requires a strong power supply. Please ensure that your power supply is sufficient to support this platform. (At least a 500w brand power supply is required)

(5) The battery in the motherboard photo is not included. It will be removed before shipment as the logistics requirements prohibit the use of this battery.
